Powerful Engine: Equipped with a 162 kW Weichai engine for robust performance.
5 Ton Capacity: Ideal for handling heavy loads in mining and quarrying operations.
Hydraulic Pump by HYDAC: Ensures smooth and efficient operation.
China Origin: Built with high-quality components and standards.
1-Year Warranty: Peace of mind with extended coverage.
| ltem | Parameters | Unit |
| Rated load | 5000 | kg |
| Rated bucket capacity | 3 | m³ |
| Total weight | 17500 | kg |
| Dumping height(from ground to main blade plste) | 3090 | mm |
| Dumping distance(from the front wheel to main blade plate) | 1130 | mm |
| Maximum breakout force | 170 | KN |
| Max.tractive force | 165 | KN |
| Lifting time of swing arm | ≤6.5 | s |
| Total cycling time | ≤11 | s |
| Minimum turning radiu | 7300 | mm |
| Maximum turning radi | 6400 | mm |
| Articulated angle | 35 | ° |
| Gradeability | 30 | ° |
| tire size | 23.5-25 | |
| Overall demension of machine(L×W×H) | 8165×3016×3485 | mm |
| Engine model | WD10G220E23 | |
| Rated power/rotate speed | 162/2000 | kW/r/min |
