3 Ton Capacity: Ideal for heavy-duty mining and construction tasks.
China Origin: High-quality engineering and durability.
Weichai Engine: Reliable power for efficient operations.
1-Year Warranty: Peace of mind with extended coverage.
HYDAC Hydraulics: Precision control for smooth performance.
| Item | Specification | Unit | |
| Rated operating load | 3000 | kg | |
| Bucket capacity | 1.5~2.5 | m³ | |
| Machine weight | 10900±200 | kg | |
| Dump clearance at maximum lift | 2770~3260 | mm | |
| Reach at maximum lift | 1010~1210 | mm | |
| Wheel base | 2900 | mm | |
| Tread | 1850 | mm | |
| Height of hinge at maximum lift height | 3830 | mm | |
| Working height(fully lifted) | 4870 | mm | |
| Max.breakout force | 130 | kN | |
| Max.horse power | 95 | kN | |
| Hydraulic cycle time-raise | 5.4 | s | |
| Total hydraulic cycle time | 9.3 | s | |
| Min. turning radius over tyres | 5170 | mm | |
| Articulation angle | 38±1 | ° | |
| Gradeability | 28 | ° | |
| Tyre size | 17.5-25-12PR | ||
| Overall machine dimension L×W×H | 7245×2482×3320 | ||
| Model | WP6G125E201 | ||
| Emission standards | Emission 2 | ||
| Rated Power/Speed | 92/2200 | kW/rpm | |
| Fuel Tank | 170 | L | |
| Hydraulic Tank | 175 | L | |
| Travel speed | Ⅰ-gear(F/R) | km/h | |
| Ⅱ-gear(F/R) | 38/- | km/h | |
