The customized low-speed and high-torque engine is accurately matched with the hydraulic system, reducing fuel consumption by more than 5%, increasing the fuel
tank volume by 18%, increasing the size of the body and chassis, and matching the large-capacity bucket, making the operation more stable and powerful. The hydraulic
lock of the bulldozer is standard , protect driver safety; The newly optimized second-generation main valve has soft control, smooth movement, and more precise micro-
operation.
The maintenance-free rotary motor has a 13% increase in rotary torque and The work is easier, the response speed of the main pump is improved, the system responds
quickly, and there is no delay in action;
Enlarged luxury cab, one-touch start switch, touch high-definition instrument, all vehicle information at your fingertips, in-car Bluetooth, and audio with multiple sound
effect modes sound system;
Vehicle-level NVH optimization, lower vibration and noise; high-power automatic heating and cooling air conditioning, three-dimensional surround air supply; fully sealed
positive pressure cab, Standard fresh air system; flip-up armrest box, cab passing space increased by 15%;
The hood has a large opening angle and is convenient for maintenance.
The radiator, three engine filters, and components in the engine room can be easily maintained and maintained at a glance; Buckets of various specifications are
available, and a variety of tools such as breakers and augers can be installed to meet the needs of different working conditions.
| Operation Weight | 6050 kg | |
| Bucket Capacity | 0.25 m ³ | |
| Main performance | Travel speed(H/L) | 4.2/2.4 km/h |
| Rotating speed | 10 r/min | |
| Gradeability | 35° | |
| Ground pressure | 32.5 kPa | |
| Bucket digging force | 48.3 kN | |
| Arm digging force | 32.5 kN | |
| Maximum traction | 50.5 kN | |
| Hydraulic system | Rated flow of main pump | 151.2 L/min |
| Pressure of prime valve | 24.5 Mpa | |
| Pressure of travel system | 22 Mpa | |
| Pressure of swing system | 21 Mpa | |
| Pressure of pilot system | 3.5 Mpa | |
| Oil capacity | Fuel tank capacity | 110 L |
| Hydraulic tank capacity | 85 L | |
| Engine oil capacity | 12 L | |
| Appearance size | Overall dimensions(L*W*H) | 5860×1920×2585 mm |
| Width of platform | 1780mm | |
| Width of crawler | 400 mm | |
| Clearance under counterweight | 700 mm | |
| Min. ground clearance | 385 mm | |
| Min. tail swing radius | 2890 mm | |
| Working scope | Max. digging height | 5630 mm |
| Max. dumping height | 3945 mm | |
| Max. digging depth | 3830 mm | |
| Max. vertical wall digging depth | 2680 mm | |
| Max. digging reach | 6130 mm | |
| Min. swing radius | 2460 mm | |
| Standard | Boom length | 3000 mm |
| Arm length | 1600 mm | |
