XCMG QY25K5D 25 ton truck crane the operations of crane are very simple, convenient and flexible.
It is widely used for lifting operation and installation work in urban renewal, transportation, ports, bridges, oilfield,
industrial and mining enterprises, etc.
performance characteristics:
- Truck crane QY25K5D adopts U-shaped cross-section boom has small depth-width ratio, strong bearing capacity, small
deformation, strong anti-bending and powerful lifting capacity. The main boom length is 10.6m to 41.0m, the performance of mid-extended boom and fully-extended are also superior.
2. Plug-in boom head effectively increases the boom connect length and reduces boom deformation.
3. Truck crane QY25K5D embedded sliders are equipped, which enlarge the contact square and reduce the contact stress of boom.
4. Truck crane QY25K5D with 9-speed transmission equipped, it has superior travel and grade ability. The max. grade abilities 40%,
max. travel speed is 90km/h.
5.Meets the requirements of speed and reduces the energy consumption and system heat effectively.
| Dimension | Unit | QY25K5D |
| Overall length | mm | 12300 |
| Overall width | mm | 2500 |
| Overall height | mm | 3350 |
| Total weight in travel | kg | 31750 |
| Front axle load | kg | 6550 |
| Rear axle load | kg | 25200 |
| Engine model | SC8DK280Q3 | |
| Engine rated power | kW/(r/min) | 206/2200 |
| Engine rated torque | N.m/(r/min) | 1112/1400 |
| Max. travel speed | km/h | 80 |
| Min. turning diameter | m | 22 |
| Min. ground clearance | mm | 260 |
| Approach angle | ° | 16 |
| Departure angle | ° | 13 |
| Max. grade ability | % | 40 |
| Fuel consumption for 100km | L | ≈37 |
| Max. rated total lifting capacity | t | 25 |
| Min. rated working radius | mm | 3000 |
| Turning radius at turntable tail | m | 3.065 |
| Max. lifting torque | kN.m | 961 |
| Base boom | m | 10.4 |
| Fully extended boom | m | 39.5 |
| Fully extended boom+jib | m | 47.8 |
| Longitudinal outrigger span | m | 5.14 |
| Lateral outrigger span | m | 6 |
| Boom luffing time | s | 68 |
| Boom full extension time | s | 150 |
| Max. swing speed | r/min | 2.5 |
| Max. speed of main winch (single rope) (no load) | m/min | 125 |
| Max. speed of aux. winch (single rope) (no load) | m/min | 125 |
